Product Details:
|
| Measurement Range: | 0---4000 | Measurement Items: | Retroreflective Coefficient Mcd.m-2.lx-1 |
|---|---|---|---|
| Light Source Color Temperature: | 2856±50K | Warranty: | 1 Year |
| SD Card: | 8G | Test Data Information: | More Than 99,999 |
| Retroreflective Coefficient: | 3 Seconds | The Whole Machine Net Weight: | 2.85Kg |
| The Total Weight: | 9Kg | The Whole Machine Size: | L310*W140*H230（mm） |
| Highlight: | High Brightness Reflectometer For Road Marking,2856K Reflectometer For Road Marking,8G Retroreflectometer For Road Markings |
||
1 year Warranty and high brightness LCD transparent touch screen Of Retroreflector Meter For Road Markings
Rretroreflective marking measuring instrument is designed and developed according to relevant international technical documents and national standards and specifications. It Complies with No. 72 published by the International Commission on Illumination (CIE), ASTM D4061-94 in the United States, DIN67520 and 67521 in Germany, and GB/T 26377-2010 "Retroreflective Measuring Instrument", GB/T 16311-2009 "Quality of Road Traffic Markings" Requirements and Monitoring Methods", JJG (Traffic) 059-2004 "Verification Regulations for Retroreflective Measuring Instruments", DB36T978-2017 "Rainy Night Road Traffic Reflective Line Quality Requirements and Testing Methods", DB51T 2429-2017 "Rainy Night Highway Traffic Reflective Line Quality requirements and testing methods", JJF1809-2020 "Retroreflectance Measuring Instrument Calibration Specification" and other relevant standards.
The geometric condition of R6116-type rainy night road marking retroreflectometer is to simulate the brightness that the driver observes in the cab reflected from the marking made of retroreflective material on the road by the headlamp when the vehicle is driven on the road at night.
Main technical parameters
| Measuring aperture area | 450mm x65mm |
| Error of repeatability measurement | ≤5% |
| Angle of incidence | 88.76° |
| Observation angle | 1.05° |
| Complementary angle | 1.24° |
| Measurement range | 0---4000 |
Packing list
| Serial number | Name Specification | Number |
| 01 | Retroreflectiometer For Road Markings | 1 |
| 02 | Charger | 1 |
| 03 | USB Date Line | 1 |
| 04 | Instructions | 1 |
| 05 | Certificate | 1 |
| 06 | Warranty Card | 1 |
| 07 | Calibration Board | 1 |
| 08 | Stylus | 1 |
PICTURES
Our Service
Customized Logo
Free logo printing will be offered if order quantity is above 1pcs.
Our Warranty
1 Years warranty for all customers .
Spare Parts
A proportion of spare parts will be shipped along with formal orders.
Shipment
DHL , FEDEX , UPS , TNT , EMS :5-7 working days
Any other shipment way could be negoticated
