Product Details:
|
| Charger: | DC 8.4V | Error Of Reproducibility Measurement: | ≤3% |
|---|---|---|---|
| Measurement Range: | 0---1999.9 | Color: | Red |
| Instrument Size: | 220mm × 250mm × 80mm (L×H×W) | Testing Spot Diameter: | 32mm |
| Continuous Working Time Of Battery: | ＞8h | Built-in Battery Capacity: | 3500mAh |
| High Light: | Red Road Sign Retroreflectometer,8h Continuous Working Battery Sign Retroreflectometer,Traffic Retro Reflective Meter |
||
Sign Retroreflectometer is a professional instrument used in the sign industry to measure retroreflective coefficient. It provides an accurate and reliable way to measure retroreflection performance of a variety of materials, including reflective signs, traffic signs, and road markings. Featuring a built-in battery capacity, this instrument is light and portable in size. It has a wide measurement range of 0~1999.9, and a testing spot diameter of 32mm with an angle of incidence of -4°. It can measure multiple items, such as the retroreflective coefficient Cd .lx-1 .m-2, under an ambient humidity of less than 98% and no frost. Moreover, its light source color temperature has an adjustable range of 5,000K to 6,500K. This Sign Retroreflectometer is an ideal choice for sign professionals and engineers to inspect the retroreflective performance of a variety of materials.
| Parameters | Specification |
|---|---|
| Testing spot diameter | 32mm |
| Color | Red |
| Measurement items | Retroreflective Coefficient Cd .lx-1 .m-2 |
| Measurement range | 0---1999.9 |
| Ambient humidity | ＜98%, No Frost |
| Observation angle | 0.2° |
| Angle of incidence | -4° |
| Error of repeatability measurement | ≤2% |
| Error of reproducibility measurement | ≤3% |
| Warranty | 1 Year |
Sign Retroreflectometer is a brand-name product, model number STP-TSR, certified by CCC and originated in China. The minimum order quantity is 1, and each package contains an inner box and a master carton, with one piece per carton. It takes 5-8 work days for delivery, and payment can be made with T/T. It has a supply ability of 1000.
The product measures the Retroreflective Coefficient Cd .lx-1 .m-2, and it has an angle of incidence of -4°. It is powered by a 3500mAh built-in battery, and its light source has a color temperature of 2856±50K, according to the Standard Illuminant A. Moreover, it has a red color.
Brand Name: Retro Reflective Meter
Model Number: STP-TSR
Place of Origin: CHINA
Certification: CCC
Minimum Order Quantity: 1
Packaging Details: inner box and master carton , 1pc per carto
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 1000
Angle of incidence: -4°
Charger: DC 8.4V
Instrument size: 220mm × 250mm × 80mm (L×H×W)
Continuous working time of battery: ＞8h
Observation angle: 0.2°
Sign Retroreflectometer offers the highest accuracy for error of repeatability measurements. It is also equipped with a built-in battery capacity, allowing a continuous working time of battery for more than 8 hours. With an angle of incidence of -4°, charger of DC 8.4V, instrument size of 220mm × 250mm × 80mm (L×H×W) and observation angle of 0.2°, Sign Retroreflectometer offers the best performance.
Sign Retroreflectometer Technical Support & Services
We provide technical support and services for our Sign Retroreflectometer to our customers. Our experienced technical team is available to help with any questions, troubleshooting, and maintenance. We offer a variety of services including:
We strive to provide the best customer service possible and are committed to helping our customers get the most out of their Sign Retroreflectometer.
The Sign Retroreflectometer is packaged securely in a sturdy cardboard carton with inner foam cushioning for protection.
The carton is designed to withstand rough handling during shipment. It is marked with the shipping address, return address, and the contents of the package.
The package is shipped via a reliable shipping carrier.
